Dishwashers, laundry

Body and tank in stainless steel construction 18/10 AISI 304. Tunnel composition: 1 Pre-wash - wash arms: 3 upper + 2 lower - 34 l, 1 Wash (wash arms: 4 upper + 3 lower) - 76 l, 1 Rinse (rinse arms: 1 upper + 1 lower) - 340 l. Completely automatic. Upper and lower fixed washing (60°C), rinsing (85-90°C). Washing and rinsing arms in stainless steel constructions, easy disassembly and interchangeable. Double skin with thermic and acoustic insulation. Drawing washing tanks with rounded edges; guarantee the highest hygiene. Stainless steel self-draning inclined washing pumps. The drain valve allows to automatically empty the tanks. WRS system: recovery rinse water in Pre-washing. Counterbalanced door. Front panel composition: Low tension keyboard drives; A Digital display indicates the temperatures of different tanks; Sequential visualization of inlet/washing/rinse water temperature; Single visualization of the other temperatures through push selector switch; PCB-board programming according to the type of machine and to the customer’s demand; Alerts and functions showed on a display; Warning light indicating “door open” or absence of overflow (when present); Limit switch alarm; Water-fail alarm (tank loading); Fluxmeter alarm (when present); Thermic relays alarm motors; Signaling of various functions and cycles starting; Rinse boiler filling at daily starting; Speed selection push button or machine running with motor drive off; Drying push button and light (when present); Pre-rinse push button and light (when present); Autotimer push button and light (when present); Rinse light; Fluxmeter light (when present); Basket entry light (when present); Washing tank water level light; Heath pump light. The “SERVICE” function allows to program the maintenance interventions. Autotimer allows to reduce water and energy consumption. Frontal maintenance. Water protection (PM). Automatic tank loading. Thermostat for automatic control temperatures of the wash- and rinse water. Rinse economizer. Tank and pump filters. Insulated Boiler. Safety: Feet adjustable and strong; Pressure-switch protection for Heating elements; Thermic protection for washing pump; Automatic stopping of pull-through in case of foreign bodies; Low voltage control circuit (24V) for greater safety during work operation; Dishes (Stop with End Micro-switch on the exit table). Door opening safety device. Technical specifications: automatic feed; 1st speed: 1,080 mt/m', 2nd speed: 1,580 mt/m', hour capacity: 2080/3040 dishes/H, hour baskets production: 130/190; max dimensions for wash: 420 mm height - 500 mm width; basket dimensions: 500x500 mm. Accessories: 5 baskets. Optionals: water protection (standard and with aspirator); drying tunnel; steam condenser; heat pump; automatic start; rinsing flowmeter; entry-exit table; automatic basket-unload table; pressure pump, washing economizer. Cold water connection upon request.
